Electrovalve 2

Description

FEATURES

• Application : residential/light commercial
• External and internal manual bleed allows quick and easy "at the valve" activation
• Double-beaded diaphragm seal design for superior leak-free performance
• DC latching solenoids enable Hunter's battery-powered controllers
• Captive bonnet bolts provide hassle-free valve maintenance
• Low flow capability allows use of Hunter's micro-irrigation products
• Encapsulated 24VAC solenoid with captive plunger for hassle-free service
• Temperature rating : 66^oC
• Flow control
• Accu-Sync capable

OPERATING SPECIFICATIONS

Flow rate : 5 to 34mc/h, 75 to 570l/min

Recommended pressure range : 1.5 to 10bar; 150 to 1000kPa

SOLENOID SPECIFICATION

24VAC solenoid, 370mA inrush, 190mA holding, 50Hz

DIMENSIONS

20cm H x 17cm L x 13cm W
