Description
Well-secured
Thanks to flow monitoring and thermal dry-run protection
Easy to see – easy to access
On the rear of the handle, a pressure switch is attached on top with 3x coloured LEDs for clear and quick status display
Easy commissioning
Fast and funnel-free filling through the pre-filter. Any residue from the filling water remain in the filter
Flow monitoring ensures a long pump life
High-volume and flow-optimised hydraulic unit of fibre-glass reinforced plastic and optional 5-stage pump mechanism (6000/5)
Stainless steel motor cladding for improved heat dissipation
Integrated non-return valve for reliable standby operation and with practical valve opener for the trouble-free initial filling
Rubber feet and vibration dampers are integrated onto the supporting base
4x slots for threaded fittings in the base allow variable mounting, e.g. on an existing installation carriage
The metal drain screw ensures reliable opening and closing with a tool
|
3500
|
4000
|
5000
|
6000/5
|
Dimensions (L x W x H)
|
543 x 234 x 304mm
|
543 x 234 x 304mm
|
543 x 234 x 304mm
|
543 x 234 x 304mm
|
Rated voltage
|
230 V / 50 Hz
|
230 V / 50 Hz
|
230 V / 50 Hz
|
230 V / 50 Hz
|
Power consumption |
900W
|
1100W
|
1300W
|
1400W
|
Power cable length
|
1.5m
|
1.5m
|
1.5m
|
1.5m
|
Net weight
|
11kg
|
11.2kg
|
11.4kg
|
14.3kg
|
Flow rate – Q max.
|
3500 l/h
|
4000 l/h
|
5000 l/h
|
6000l/h
|
Delivery head – H max.
|
40m
|
45m
|
50m
|
60m
|
Suction line / pressure line
|
1" (33.3 mm)
|
1” (33.3 mm)
|
1” (33.3 mm)
|
1" (33.3 mm)
|
Self-priming suction head – max.
|
8m
|
8m
|
8m
|
8m
|
Pump mechanism
|
Jet
|
Jet
|
Jet
|
5-level
|
Automatic function
|
Da
|
Da
|
Da
|
Da
|
Sprinkler connection capacity / max. hose length per sprinkler* |
2x / 25m
2x / 50m
|
3x / 25m
3x / 50m
|
4x / 25m
4x / 50m
|
5x / 25m
5x / 50m
|
Pressure – max.
|
4 bar
|
4.5 bar
|
5 bar
|
6bar
|
